MSI GeForce RTX™ 5090 32G SUPRIM LIQUID SOC – Flagship Liquid-Cooled Blackwell GPU
The MSI GeForce RTX™ 5090 32G SUPRIM LIQUID SOC represents the peak of MSI’s engineering and NVIDIA’s Blackwell GPU technology. With an immense 32GB of ultra-fast GDDR7 memory on a 512-bit interface, it’s designed for uncompromising performance in 4K and 8K gaming, AI-driven workflows, and extreme enthusiast builds. The SUPRIM LIQUID SOC integrates a premium closed-loop liquid cooling system to deliver unmatched thermals and ultra-quiet operation, allowing the RTX 5090 to sustain peak boost clocks with stability.
Core Specifications
-
GPU: NVIDIA® GeForce RTX™ 5090 (Blackwell architecture)
-
CUDA Cores: TBA (~16,000+ expected)
-
Memory: 32GB GDDR7
-
Memory Interface: 512-bit
-
Boost Clock: 2497 MHz (Super Overclock – SOC Mode)
-
Bus Standard: PCI Express 5.0
Cooling & Design
-
SUPRIM LIQUID Hybrid Cooling – integrated closed-loop liquid cooler paired with a dedicated fan and radiator for maximum thermal headroom
-
Zero Frozr Technology – fans halt under idle/low loads for silent operation
-
Premium SUPRIM Design – luxury-grade metal shroud and brushed aesthetics
-
ARGB Lighting – customizable RGB accents via MSI Mystic Light
Display & Connectivity
-
Outputs:
-
1× HDMI® 2.1b
-
3× DisplayPort™ 2.1a
-
-
Max Digital Resolution: 8K (7680×4320) UHD
Power Requirements
-
Recommended PSU: 1000W+
-
Power Connector: 1× 16-pin 12VHPWR (ATX 3.0 / PCIe 5.0 compliant)
-
Typical GPU Power (TGP): ~450W (expected)
Physical Dimensions
-
Card Length: ~280 mm (11.02 inches)
-
Height: ~142 mm (5.59 inches)
-
Slot Size (Thickness): 2.5-slot (~2.0 inches)
-
Radiator Size: 240 mm AIO liquid cooling radiator (pre-installed hoses for easy fitment)
MSI Gaming RTX 5090 32G SUPRIM LIQUID SOC – Specifications
| GPU | NVIDIA GeForce RTX 5090 (Blackwell architecture, GB202-300-A1) |
|---|---|
| EXTREME PERFORMANCE (Gaming Mode) | 2,580 MHz (via MSI Center) |
| Boost | 2,565 MHz |
| SILENT Mode (EP / Boost) | 2,527 MHz / 2,512 MHz |
| CUDA Cores | 21,760 |
| FP32 Compute (Theoretical) | ~112 TFLOPS |
| Memory | 32 GB GDDR7, 512-bit @ 28 Gbps (~1.792 TB/s) |
| Interface | PCIe 5.0 ×16 (electrically ×8) |
| TDP | 600 W (Gaming Mode); 575 W (Silent Mode) |
| Power Connector / PSU | 1 × 16-pin (ATX 3.1); Recommended PSU ≥ 1000 W |
| Max Resolution | 7680 × 4320 (8K UHD) |
| Display Outputs | 3 × DisplayPort 2.1b; 1 × HDMI 2.1b |
| Thermal System | 360 mm liquid cooling radiator with StormForce fans; micro-fin copper base; metal backplate; braided PVC tubing; dual BIOS |
| Dimensions | Card: 280 × 148 × 51 mm; Radiator: 394 × 121 × 55 mm; Tubing length: 450 mm |
| Weight (Card / Packaged) | 2,969 g / 4,273 g |
| Maximum Displays Supported | 4 |
