MAG B860 Tomahawk WiFi Motherboard, ATX - Supports Intel Core Ultra Processors (Series 2), LGA 1851 - DDR5 Memory Boost 9200+ MT/s OC, 1 x PCIe 5.0 x16, 1 x M.2 Gen5, 5G LAN, Wi-Fi 7
The MSI MAG B860 TOMAHAWK WIFI is a robust ATX motherboard tailored for 14th‑ and 13th‑Generation Intel Core processors. Engineered for gamers and creators, it blends high-end connectivity, reliable power, and modern features.
Key Features & Specifications
-
Socket & Chipset: Intel LGA1700 socket with B860 chipset, optimized for 14th/13th‑Gen Core CPUs; includes PCIe 5.0 x16 support
-
Memory Support: Four DDR5 DIMMs, up to 192 GB, with overclocking support beyond DDR5‑7600
-
Power Design: Enhanced 14‑phase power delivery system with ProCool II power connectors and fortified components for stable performance
-
Storage & Expansion: Dual M.2 slots (one PCIe 5.0 and one PCIe 4.0) plus six SATA III ports
-
Connectivity: Built-in Wi‑Fi 6E and 2.5 Gb Ethernet provide fast wireless and wired networking; multiple USB 3.2 Gen 2 ports enhance peripheral support
-
Audio & Cooling: Premium audio codec, multiple fan and pump headers, plus heatsinks on VRMs, M.2 slots, and chipset for efficient thermal management
-
Durability & Usability: Steel-reinforced PCIe slots and EZ BIOS updates deliver enhanced durability and user-friendly configuration
MSI PRO B650‑P WIFI
Platform & CPU Support
| Form Factor | ATX (305 × 243 mm) |
|---|---|
| Socket | AM5 (LGA 1718) |
| Chipset | AMD B650 |
| CPU Support | Ryzen 7000 / 8000 / 9000 Series (Socket AM5) |
Memory & Expansion
| Memory Slots | 4 × DDR5 DIMM |
|---|---|
| Max Capacity | 256 GB, dual‑channel |
| Memory Speed (OC) | Up to DDR5‑7200+ |
| PCIe Slots | 1× PCIe 4.0 x16 (Steel Armor) 1× PCIe 4.0 x16 (x4 mode) 2× PCIe 3.0 x16 (x1 mode) |
Storage
| SATA Ports | 6 × SATA 6 Gb/s (RAID 0/1) |
|---|---|
| M.2 Slots | 2× Key M (PCIe 4.0 x4, 2280/22110 & 2260/2280) |
Networking & I/O
| LAN | Realtek 2.5 GbE |
|---|---|
| Wi-Fi | Wi‑Fi 6E (M.2 Key E module) & Bluetooth 5.2/5.3 |
| USB (Rear) | 1× USB‑C 20 Gb/s (Gen 2×2) 3× USB‑A 10 Gb/s (Gen 2) 4× USB‑A 5 Gb/s (Gen 1) |
| Video Outputs | 1× HDMI 2.1, 1× DisplayPort 1.4 |
Power & Cooling
| VRM | 12+2+1 Duet‑Rail 75A Smart Power Stage |
|---|---|
| Power Connectors | 1× 24‑pin ATX 2× 8‑pin CPU |
| Cooling Features | Extended heatsinks, 6‑layer 2 oz copper PCB, M.2 Shield Frozr |
Audio & Debug
| Audio Codec | Realtek ALC897, 7.1‑channel |
|---|---|
| Debug | EZ Debug LED, Flash BIOS Button |
Additional Features
| BIOS | Dual BIOS |
|---|---|
| MSI Tech | Core Boost, Memory Boost, Lightning Gen4, EZ M.2 Clips, Steel Armor |
| Software | MSI Center, Mystic Light, Frozr AI Cooling |
